Name: QC Inspection Fruit Sorter Machine 1200mm Width Fruit Sorting Equipments
Brand: PHOENIX
Price: 1 USD

Belt Width (mm) : 1200

Air Nozzle : 256

Air Pressure (MPa) : 0.6~0.8

Mode : QC4

Brand Name : PHOENIX

Model Number : QC Inspection Machine

Place of Origin : Hefei

MOQ : 1

Price : Price Negotiable

Payment Terms : L/C,D/A,D/P,T/T,,

Delivery Time : 5-8 work days

Contact Now

QC Inspection Machine Ultimate Quality Control By AI After The Processing Of Regular Sorters, Replacing The Traditional Manual Inspection

Technical Features

Tailored Ultimate Quality Guardian for Dehydrated Vegetables
Compact single-belt sorting system with quick-install design
Innovative high-capacity 3-layer vibratory feeder evenly distributes dehydrated vegetables into a single layer to minimize overlapping
Food-grade stainless steel structure complies with global food safety and hygiene standards
Sealed scanning and control boxes provides machine with high-level dust protection
Quick belt change ensures convenient routine maintenance and cleaning, meeting higher food safety and hygiene standards
Field-proven Dust Control System integrated ensures high operation reliability and performance consistency, and minimizes downtime

AI Powered 4-in-1 Multispectral Inspection System

Proprietary AI Deep Learning algorithms continuously improve defect recognition based on new samples
Ultra-High-Resolution RGB Camera System
High-Intensity LED Illumination System
Optional NIR Camera System or HSI Camera System
Unprecedentedly high-precision detection to subtle contaminants of dehydrated vegetables by color, size, shape and texture features:
Hair
Fibers
Low-density plastics

High-Performance Rejection System

Optional Air Nozzle Rejection System and Drop Flap Rejection System
Engineered to achieve Ultimate Quality Control by zero-tolerance rejection and reliable performance

QC Inspection Fruit Sorter Machine 1200mm Width Fruit Sorting Equipments

Specifications

Model	Belt Width (mm)	Air Nozzle	Air Pressure (MPa)	Air Consumption (m³/min)	Voltage	Power (kW)	Dimension (mm)	Unpacked Weight (kg)
QC4	1200	256	0.6~0.8	<3.6	220V~50/60Hz	3.9	410224432125	1097
